Why Choose the ZS-360 for Mask Production?
Mask manufacturing requires speed, hygiene, and flexibility. The ZS-360 addresses the specific challenges of packing face masks:
Multi-Pack Versatility: Unlike basic machines that only pack singles, the ZS-360 allows you to switch between Single Packs (for pharmacy sale) and Bulk Packs (10 pcs for family use) simply by adjusting the bag length and height.
Protect the Ear Loops (Anti-Cut): Mask ear loops often get caught in the cutter of older machines. The ZS-360's Safety Reverse Function detects resistance and instantly reverses the cutter, preventing the blade from slicing through a mask or its straps.
Hygienic Operation: The machine's contact surfaces are easy to clean, and the servo system minimizes mechanical contact, reducing the risk of contamination.
Application Scenarios & Capacity
This machine is optimized for:
Disposable Flat Masks (Surgical/Medical):
Capacity: 1-10 pieces per bag.
Note: Ideal for "Inner Ear" loop masks. For "Outer Ear" masks, loops must be folded inward before packing to ensure smooth transport.
KN95 / N95 / FFP2 Respirators:
Other Hygiene Products: Also suitable for packing alcohol wipes (in trays), medical gloves, and instruction manuals.
Key Features & Technical Highlights
Servo Precision: "Set and Cut" technology means no film is wasted on calibration. The bag length is adjusted instantly via the touchscreen—vital when switching from 1-pack to 10-pack settings.
Smart Memory: Store up to 40 product recipes. Save settings for "KN95 Single" and "Flat Mask 10-Pack" for instant changeovers.
Automatic Stop: The machine automatically halts if the film runs out or if no product is detected, preventing empty bags and wasted film.
Independent PID Temp Control: Ensures airtight, hermetic seals on various film types (OPP, PE, CPP), protecting the masks from moisture and dust.
High-Speed Output: Capable of running at 20-220 bags/minute, matching the output of high-speed mask body machines.
Technical Specifications
Parameter | Specification |
Model | ZS-360 (Mask Edition) |
Control System | Servo Control (PLC + Touchscreen) |
Mask Capacity (Flat) | 1 - 10 pieces/bag |
Mask Capacity (KN95) | 1 - 2 pieces/bag |
Packaging Speed | 20 - 220 bags/min |
Bag Length | 80 - 1000 mm |
Bag Width | 40 - 160 mm |
Product Height | Max 60 mm |
Film Width | Max 360 mm |
Power Supply | 220V, 50/60Hz, 2.9KW |
Machine Dimensions | (L)4020 × (W)1060 × (H)1520 mm |
Machine Weight | 500 Kg |
Service & Support
Feeder Integration: Can be integrated with automatic friction feeders for instruction manuals or certificates to be inserted into the mask pack automatically.
Sample Testing: Send us your specific mask type. We will configure the bag former to ensure a tight, professional fit.
Warranty: 1-Year Warranty on core components (Servo/PLC) with lifetime technical support.
Frequently Asked Questions (FAQ)
Q: Can I pack 50 masks in one bag with this machine?
A: No. The ZS-360 is designed for retail packs (1-10 pcs). For bulk packing (50 pcs), you would need a larger reciprocating machine (like our ZS-500S or ZS-720W) due to the height of the stack.
Q: Do I need to fold the masks manually?
A: For flat masks, they are usually fed into the conveyor in a stack. If you are packing "Outer Ear" masks (where loops stick out), they must be folded. "Inner Ear" masks can be fed directly.
Q: Can it pack masks with individual sterilization?
A: Yes, the machine supports medical-grade packaging materials (paper/plastic) and the PID temperature control ensures a hermetic seal suitable for sterilized products.
Upgrade Your Mask Packaging Line.
Ensure your medical products are packed securely, hygienically, and efficiently. Switch to the ZS-360 for versatile multi-pack capabilities.
Get a Quote: Contact us for pricing and delivery.
Request a Video: See the ZS-360 packing 10 masks at high speed.
Consult an Engineer: Discuss your specific mask dimensions.
