Why Choose the JXSBF-250?
Packaging medical disposables requires higher standards than food packaging. The JXSBF-250 delivers:
Superior Sealing (Reciprocating Tech): The machine uses a reciprocating heat sealing mechanism. Unlike rotary rollers, this method applies constant pressure and heat for a specific dwell time, ensuring a 100% airtight seal to maintain sterility.
4-Side Seal Format: Creates a professional, flat, and thin package that is easy to stack and sterilize. Perfect for thin, sheet-like materials.
Servo Intelligence: The entire operation—traction, feeding, and cutting—is driven by servo motors and PLC. This ensures precise bag lengths and minimizes mechanical noise and maintenance.
Application Scenarios
Designed for thin, sheet-like medical and daily care products:
Medical Dressings: Wound plasters, non-woven dressings, transparent waterproof dressings.
Gauze & Cotton: Sterile gauze pads, cotton pads, surgical sponges.
Therapeutic Patches: Cooling gel patches (fever patches), pain relief patches, warm patches.
Personal Care: Facial mask sheets (dry), screen cleaning wipes.
Key Features & Technical Highlights
Visualized Control: The touchscreen displays real-time data including speed, bag length, cutting time, heat sealing time, and total output. Everything is adjustable digitally.
Precision Registration: High-accuracy photoelectric sensors track the color mark on the film, ensuring your branding and text are perfectly aligned on every pouch.
Dual Temp Control: The heat-sealing area uses two independent sets of temperature controllers. This allows precise heat management for different film materials (e.g., Paper/Poly vs. Aluminum/PE), improving seal quality.
Programmable Operation: From feeding to finished conveyor, the entire process is automated via PLC, reducing the need for manual intervention.
Important Film Requirements
Material: Compatible with heat-sealable composite films (Paper/PE, AL/PE, etc.).
Paper Film: If using medical paper, it must be coated with heat-seal glue/layer.
Registration: The eye-mark (cursor) should be printed on one roll (usually the top web). The machine is designed to track a single cursor source for alignment.
Technical Specifications
Parameter | Specification |
Model | JXSBF-250 |
Sealing Type | 4-Side Seal (Reciprocating) |
Production Capacity | 50 - 150 bags/min (Depends on material) |
Packaging Size | **L: 100-200mm |
Film Width | Max 250 mm |
Film Roll Diameter | Max 350 mm (Core: 76mm) |
Control System | Servo Motor + PLC |
Air Pressure | 0.5 - 0.7 Mpa (Consumption: 0.3m³/min) |
Total Power | 9.3 KW (High Power for Reliable Sealing) |
Voltage | AC 220V, 50Hz |
Machine Dimensions | (L)5148 × (W)876 × (H)1552 mm |
Machine Weight | 1200 Kg |
Service & Support
Custom Molds: We can customize the sealing mold pattern (e.g., grid, line, or smooth seal) based on your medical requirements.
Validation Support: We can assist with IQ/OQ validation documentation for medical device manufacturers.
Warranty: 1-Year Warranty on core components.
Frequently Asked Questions (FAQ)
Q: What is the difference between this and a Pillow Packaging Machine (like ZS-360)?
A: A pillow machine creates a bag with a back seal (fin seal). The JXSBF-250 creates a flat pouch sealed on all 4 sides. The 4-side seal is generally considered more premium and secure for flat medical products.
Q: Can it pack thick products?
A: No. This machine is designed for sheet-like materials with a height of 1-10mm. For thicker items, a pillow packaging machine is better.
Q: Does it support Tyvek or Medical Paper?
A: Yes, as long as the material has a heat-sealable coating. The independent temperature control ensures proper sealing even on difficult medical papers.
Ensure Sterility with Professional 4-Side Sealing.
Upgrade your medical dressing production line with the precision of the JXSBF-250.
