Why Choose the JX-580X?
Wider Packaging Range: The 580mm film width allows you to pack items up to 250mm wide. Ideally suited for bulky items like fresh vegetable trays, multi-pack tissues, or textiles (towels/socks) that require a wider bag.
Global Brand Components: Unlike cheap alternatives, we use globally recognized parts.
Servo System: VEICHI (Reliable motion control).
Electrics: SCHNEIDER (France) & IDEC (Japan).
Sensors: AUTONICS (Korea).
Benefit: If a part ever needs replacement after years of use, you can find these brands locally anywhere in the world.
Intelligent 3-Servo Drive: No mechanical chains or gears for the main drive. The belts, film feed, and cutter are independently driven by servo motors, ensuring quieter operation and less maintenance.
Application Scenarios
Designed for "Medium-Large" regular objects:
Bakery: Family-size bread loaves, baguette multipacks, tray-loaded cakes.
Textiles & Daily Use: Towels, folded bedding, socks (bundles), disposable slippers, diapers.
Hardware: Long plastic pipes, oversized bearings, automotive parts.
Fresh Produce: Leafy vegetables (Spinach/Celery) requiring long bags.
Key Features & Technical Highlights
Anti-Cut Safety (Smart Reverse): If the cutter hits a product (e.g., a hard plastic tray), the machine automatically reverses the cutter and stops. This protects both your product and the knife blade.
No Film, No Run: The machine automatically detects if the film roll is empty and shuts down to prevent dry cycling.
Long Product Capability: Can produce bags up to 1 meter (1000mm) in length, making it one of the most versatile machines for long hardware or vegetables.
User-Friendly HMI: The VEICHI color touchscreen allows you to store 40 product recipes. Changing from a small pack to a large pack takes just seconds.
Premium Configuration List
We believe in quality you can see. Here is the core configuration of the JX-580X:
Component | Brand / Origin | Model / Spec |
Servo System (PLC/Motion) | VEICHI (Top Tier China) | V5-MC104 Motion Controller |
Touch Screen (HMI) | VEICHI | 7-inch Color (VI20-070S-F) |
Servo Motors (3 Units) | VEICHI | High-Precision Servo Motors |
Circuit Breakers | SCHNEIDER (France) | EA9AN1C20 |
Intermediate Relays | SCHNEIDER (France) | RXM Series |
Temp. Control | AUTONICS (Korea) | PID Control (TCN4S) |
Switches / Buttons | IDEC (Japan) | Industrial Grade |
Solid State Relay | FOTEK (Taiwan) | SSR-40DA |
Power Supply | DELTA (Taiwan) | 24V Stable Supply |
Technical Specifications
Parameter | Specification |
Model | JX-580X |
Control Type | 3-Servo Motor Control |
Packaging Speed | 20 - 120 bags/min |
Bag Length | 120 - 1000 mm |
Bag Width | 100 - 250 mm |
Product Height | Max 75 mm |
Film Width | Max 580 mm |
Power Supply | 220V, 50/60Hz, 4.25KW |
Machine Dimensions | (L)4207 × (W)1070 × (H)1510 mm |
Machine Weight | 650 Kg |
Frequently Asked Questions (FAQ)
Q: Why is the speed (120 bags/min) lower than smaller machines?
A: The JX-580X is designed for larger, heavier, or longer products. Moving a large product requires more stability. However, 120 bags/minute is still very fast for bulk packaging.
Q: Can I pack a product that is 200mm wide?
A: Yes, the machine supports bag widths up to 250mm, so a 200mm wide product fits perfectly.
Q: Is the machine difficult to maintain?
A: No. Because it uses a 3-Servo system, the mechanical transmission is very simple (fewer chains/gears). Plus, with Schneider and Veichi components, the electrical system is extremely durable.
Pack Bigger, Pack Better.
Don't force large products into small machines. Upgrade to the JX-580X for professional, wide-format packaging with world-class components.
Get a Quote: Contact us for the best price on this high-spec machine.
Check Compatibility: Send us your product dimensions (L x W x H).
Virtual Tour: Ask for a video call to see the internal components.
