Neat Folded Corners, Every Time
The film folding system delivers tight, uniform corner pleats on each roll. The result is a clean retail-ready appearance that supports shelf presentation for your customers downstream.
Fully Automatic from Feed to Output
An integrated vibrating bowl auto-sorts and feeds tape rolls without manual loading. Once set up, the machine runs at 68–72 pcs/min with minimal operator involvement — reducing direct labor cost per unit significantly.
Stable PLC Control, Easy to Operate
The touch screen PLC panel gives operators real-time visibility into production status and makes parameter adjustments straightforward. No specialized programming knowledge is needed for daily operation.
Handles a Wide Range of Tape Sizes
Compatible with tape roll diameters up to 120 mm and widths from 10 mm to 25 mm (up to 75 mm on production line models). Switching between product sizes takes approximately 15–20 minutes with tooling changeover.
Line-Ready for Tower / Tube Pack Output
The JX-50M integrates seamlessly with downstream shrink wrapping equipment. Run it standalone for single-roll fold wrapping, or connect it to the full packaging line to produce multi-roll tube packs and tower packs automatically.
The JX-50M wraps each tape roll in four stages:
1. Automatic Feeding
Tape rolls are loaded into the vibrating bowl feeding table. The bowl auto-sorts rolls into a consistent orientation and delivers them one at a time to the wrapping station.
2. Film Cutting & Positioning
BOPP (or PE/PVC/POF) film is drawn from the roll device and cut to length. The film is positioned precisely around the tape roll before folding begins.
3. Fold Corner Wrapping
The film folding system forms neat pleats at each end of the roll — the same technique used for retail gift wrapping, engineered for production-speed repeatability. Output is a tight, wrinkle-free package with clean corners.
4. Finished Product Output
Completed rolls exit via the automatic output conveyor. In a full production line configuration, rolls move directly into stacking and shrink-wrapping equipment for tube or tower pack assembly.
Standalone vs. Integrated Line
Run the JX-50M as a single station for single-roll fold wrapping at up to 72 pcs/min, or integrate it into a complete line that combines inner fold wrapping with outer shrink packaging, achieving up to 120 pcs/min on the full line.
Component | Function |
Touch Screen Control Panel | PLC-based operation; displays machine status, speed, and fault alerts in real time |
Automatic Feeding Table | Vibrating bowl auto-sorts rolls; eliminates manual feeding, reduces operator fatigue |
Film Roll Device | Smooth, tension-controlled film unwind; prevents film breaks and ensures consistent wrapping |
Film Folding System | High-precision corner pleating mechanism; produces tight, uniform folds at production speed |
Finished Product Output | Automatic discharge conveyor; supports direct connection to downstream packaging equipment |
Warning Light | Three-color status indicator; signals normal run, standby, and fault conditions at a glance |
Safety Door | Enclosed guarding with interlock; prevents access to moving parts during operation |
The machine frame is constructed from heavy-gauge steel with a powder-coated finish. All contact surfaces are designed for easy film threading and cleaning during shift changeovers.
The JX-50M produces packaging suitable for direct retail sale and export shipment. Finished samples demonstrate:
Neat Corner Folding — Uniform pleats with no loose film edges
Clear Print Display — Film lies flat against the roll face, keeping label and print fully visible
Tight Film Wrapping — No sagging or looseness; the pack holds its shape through handling and shipping
Multiple Color Compatibility — Works equally well on black, white, red, yellow, and multi-color tape rolls
Smooth, Consistent Surface — Professional finish across all roll widths and diameters
Spec Flexibility — Demonstrated on 5 m, 10 m, 18 mm, and 19 mm rolls; changeover is straightforward
Packaging film is typically BOPP (standard) or PVC/PE/POF depending on customer requirement and downstream application.
Parameter | Specification |
Model | JX-50M |
Power Supply | AC 200–240V, 50/60Hz |
Power Consumption | 0.75 kW |
Production Speed | 68–72 pcs/min |
Tape Roll Diameter | Ø 52–85 mm (machine range: ≤120 mm) |
Tape Roll Width | 10–25 mm |
Packaging Film | BOPP (PE / PVC / POF available) |
Machine Dimensions | 1750 (L) × 1730 (W) × 1350 (H) mm |
Machine Weight | 600 kg |
Voltage Options | 110V / 220V / 380V, 50/60Hz (customizable) |
Yield Rate | ≥ 99.5% |
Certification | CE |
Size Changeover Time | ~15–20 minutes |
Parameter | Specification |
Production Speed | Up to 120 pcs/min |
Tape Roll Width Range | 15–75 mm (adjustable) |
Tape Roll Diameter | ≤ 120 mm |
Power Supply | 220V, 50/60Hz, 1.5 kW |
Machine Dimensions | Customizable per layout |
Output | Single roll (fold wrap) + tube pack / tower pack |
Film roll specifications for BOPP/PE/PVC/POF can be provided to match your local film suppliers.
The JX-50M is designed for manufacturers producing tape rolls for retail and industrial distribution. Typical applications include:
PVC Electrical Tape Manufacturers
High-volume producers supplying branded PVC insulation tape for electricians, contractors, and hardware retail chains. Single-roll fold packaging is the standard retail format in most markets.
Insulation Tape & General Adhesive Tape Producers
Compatible with BOPP tape, PVC tape, insulation tape, and similar roll-format products. The same machine handles most standard roll sizes without major retooling.
OEM/ODM Contract Packaging
Facilities packaging multiple tape brands or SKUs can benefit from quick changeover (~15–20 min) between different roll sizes and film types.
Export-Oriented Production Lines
Markets including Korea, Mexico, Argentina, Vietnam, and other export destinations where retail-quality fold-corner packaging is expected. The machine supports full-line integration to increase output and reduce per-unit cost for high-volume export orders.
Multi-Roll Pack Assembly Lines
When connected to a shrink wrapper, the JX-50M feeds into tube-pack or tower-pack production — ideal for hardware stores and wholesale distributors who purchase tape in multi-roll bundles.
Q1: Can one machine handle different tape widths and diameters?
Yes. The machine accommodates tape widths from 15 mm to 75 mm and roll diameters up to 120 mm. Switching between sizes requires approximately 15–20 minutes for mechanical adjustment — no special tools or technicians needed.
Q2: Does it support both single-roll wrapping and multi-roll (tube/tower) packaging?
We offer both configurations. The JX-50M runs standalone for single-roll fold corner wrapping. For tube packs and tower packs, it connects to downstream shrink wrapping equipment as part of an integrated line. We can supply either the standalone machine or the complete line depending on your production requirements.
Q3: What film type and specification does the machine require?
Standard operation uses BOPP film. PE, PVC, and POF film are also supported. We can provide the exact film roll dimensions and core specifications so you can source compatible film from local suppliers.
Q4: Can the electrical system be configured for 110V (US / Mexico market)?
Yes. The motors, PLC, and electrical components can all be configured for 110V, 220V, or 380V at either 50 Hz or 60 Hz. Specify your local power standard when requesting a quote.
Q5: What is the yield rate for the fold corner wrapping?
The machine uses high-precision sensors and a servo-driven folding system. Yield rate is ≥ 99.5% under normal operating conditions with compatible film and correctly sized rolls.
Q6: Is OEM / ODM customization available?
Yes. We provide customized solutions covering machine dimensions, packaging size range, branding, and control system language. Contact us with your product specifications and production targets to discuss a tailored configuration.
Q7: What is the lead time after order confirmation?
Standard lead time is 15–25 working days after receipt of deposit. Complex custom configurations may require additional time; we will confirm the schedule during the quoting process.
Q8: Do you provide installation and commissioning support?
Yes. Remote technical support via video call is available for all customers. On-site overseas commissioning is also available — contact us to discuss travel arrangements and service terms for your location.
If you manufacture PVC electrical tape, insulation tape, or similar roll products and need retail-quality packaging at production scale, the JX-50M is built for that job.
We support:
Voltage customization (110V / 220V / 380V, 50/60Hz)
OEM machine branding
Full packaging line integration (fold wrap + shrink/tube pack)
Video demonstrations and remote pre-sales technical consultation
Send us your tape roll dimensions and target output speed. We'll confirm compatibility, provide a detailed quotation, and share video footage of the machine running on similar products.
