JX-77 Rotary Carton Sealing Tape Shrink Wrapper with Label Inserter

JX-77 Rotary Carton Sealing Tape Shrink Wrapper with Label Inserter


Availability:



Inquire

The Professional Standard for BOPP Tape Packaging.

The JX-77 is engineered specifically for the larger dimensions of Carton Sealing Tape (BOPP). Unlike generic shrink tunnels, this Rotary 12-Station Machine integrates the entire packaging process into one compact unit. It automatically sleeves the tape, inserts your brand label precisely inside the film, and shrinks it using built-in hot air guns. Capable of speeds up to 60 rolls/minute, it delivers a tight, retail-ready finish for tapes up to 130mm in diameter.

Model:
JX-77
Brand:
JEWSHIN

Product Brochure.pdf

Download the brochure to view specifications, features, and application details. Download Brochure

1038

Download

Product Description

Why Choose the JX-77 for Sealing Tape?

Designed for Large Rolls: Standard electrical tape machines cannot handle the 100mm+ diameter of sealing tape. The JX-77 is scaled up to handle diameters from 90mm to 130mm and widths up to 50mm.
Automated Label Insertion: Branding is key. The machine uses a Vacuum Servo Manipulator to pick a paper card and place it perfectly on the side of the sticky tape before shrinking. The Panasonic Vacuum Detector ensures no roll goes unlabelled.
Space-Saving Rotary Design: By using a turntable with a high-precision Indexer, the JX-77 performs feeding, cutting, labeling, and shrinking in a circle. This saves massive amounts of floor space compared to linear conveyor lines.
Direct Heat Shrinking: Equipped with 3KW High-Speed Hot Air Guns, it shrinks the film instantly as the table rotates. This is more energy-efficient than heating a large, empty tunnel.

Working Principle

Input: Tape rolls are fed via conveyor and pressed into the mold.
Sleeving: The Samkoon Servo feeds and cuts the shrink film (0.035-0.045mm) to the exact length, sleeving the roll.
Labeling: A robotic arm sucks a label from the magazine and places it on the roll face.
Shrinking: The roll passes through the hot air station, shrinking the film tightly.
Output: The finished product is ejected automatically.

Technical Specifications

Parameter	Specification
Model	JX-77 (BOPP Tape Version)
Packing Speed	45 - 60 pcs/min
Tape Width	15 - 50 mm
Tape Diameter	90 - 130 mm (Customizable)
Film Thickness	0.035 - 0.045 mm (50% Shrink Rate)
Power Supply	AC 380V, 4-Phase, 4.5 KW
Heating Power	3 KW (Hot Air Gun)
Air Pressure	0.5 MPa
Machine Size	1600 × 1600 × 2200 mm
Net Weight	1000 KG

Premium Configuration (Brand List)

Equipped with global and top-tier domestic components:

System	Component	Brand / Origin
Control System	PLC & HMI (10")	Haiwei (China)
Servo System	Film & Label Servos	Samkoon/Xiankong
Drive	Turntable Motor (250W)	Chenggang
	Stepper Motor (110)	Hongbaoda
Pneumatics	Cylinder / Solenoid	AirTAC (Taiwan)
	Vacuum Generator	AirTAC (Taiwan)
	Vacuum Detector	Panasonic (Japan)
Electrical	Switch / Contactor	Schneider (France)
	Photoelectric Switch	Autonics (Korea)
	Power Supply	MeanWell (Taiwan)
	Bearings	NTN (Japan)

Perfect Packaging for Your Sealing Tape.

Upgrade from manual labor to fully automated rotary packaging. Ensure every roll of your BOPP tape is labeled and shrunk to perfection.

Get a Quote: Ask for the price of the JX-77.
Check Compatibility: Send us your tape roll dimensions.
Label Design: We can advise on the best paper card thickness for the vacuum arm.
