Home / Products / Filling & Capping Equipment / Powder Filling Machine / Semi-Automatic Servo Auger Powder Filling Machine (1g - 5000g)

Semi-Automatic Servo Auger Powder Filling Machine (1g - 5000g)


Availability:



Inquire

Precision Dosing for All Powder Types.

This Semi-Automatic Auger Filler is engineered for versatility and accuracy. Powered by a high-torque Servo Motor, it drives a precision screw to dose powders ranging from 1g to 5000g. Whether you are handling free-flowing granules (like sugar) or dusty, sticky powders (like toner or flour), its "Weight Feedback Tracking" system automatically adjusts to material density changes, ensuring consistent weight every time.

Get Price

Model:
Semi-Automatic Auger Filler
Brand:
JEWSHIN

Product Brochure.pdf

Download the brochure to view specifications, features, and application details. Download Brochure

1038

Download

Product Description

Key Features & Advantages

Servo Motor Drive (High Torque & Precision):

Unlike standard motors, the Servo drive ensures the screw stops at the exact millisecond required. It provides high torque to push through dense or sticky powders without stalling.

Smart Weight Feedback (Density Compensation):

The Problem: Powder density changes with humidity or batch.
The Solution: This machine tracks the weight and automatically adjusts the screw rotations. You don't need to manually recalibrate constantly.

Hygienic & Easy to Clean:

Full Stainless Steel: All contact parts and the machine body (excluding motor) are made of stainless steel.
Suspended Hopper: The side-open hopper design allows for tool-free disassembly and washing—crucial for food and pharma GMP compliance.

Versatile Accessories (Optional):

For Free-Flowing Powders: Add a Centrifugal Device to stop the powder from leaking/flowing when the machine stops.
For Dusty Powders: Add a Dust Extraction Device to suck away the "puff" of dust when filling, keeping the seal area clean.

Application Scenarios

Food: Flour, Milk powder, Spice blends, Coffee powder, Food additives.
Pharmaceuticals/Vet: Veterinary drugs, Glucose powder, Talcum powder.
Chemicals: Toner (Carbon powder), Pesticides, Dyes.

Technical Specifications

Parameter	Details
Model Type	Semi-Auto Auger Filler
Dosing Method	Servo Screw (Auger) + Weight Feedback
Filling Range	1g - 5000g (Requires changing screw attachments)
Accuracy	≤ ±1% (Depends on material consistency)
Power Supply	380V / 60Hz (3-Phase)
Total Power	2 KW
Hopper Volume	50 Liters
Dimensions	930 × 980 × 1900 mm
Weight	~130 KG

Screw Selection Guide

To achieve the best accuracy, choose the correct screw size for your target weight:

Target Weight	Recommended Screw Diameter
5g - 50g	Ø 25mm Screw
50g - 500g	Ø 38mm Screw
500g - 1000g+	Ø 57mm Screw
(Note: Changing the screw attachment allows one machine to handle all these ranges.)

Configuration List

Reliable components for stable operation:

Component	Brand	Origin	Reliability
Servo Motor	Jinbei	China	⭐⭐⭐⭐ (High Precision Drive)
Photoelectric Sensor	Autonics	Korea	⭐⭐⭐⭐⭐ (Fast Response)
Touch Screen	Weinview	Taiwan	⭐⭐⭐⭐⭐ (Easy Interface)
Stirring Motor	Taibang	China	⭐⭐⭐⭐ (Durable)
PLC	Shanghai Brand	China	⭐⭐⭐⭐
Feeder Motor	Zhongnan	Fujian	⭐⭐⭐

Solve Your Powder Filling Headaches.

Don't let density changes ruin your accuracy. Switch to Servo control.

Material Test: Send us a sample of your powder (especially if it's sticky or dusty). We will recommend the right screw and accessory (Centrifugal vs. Dust Collector).
Get a Quote: Contact us for the Semi-Auto Servo Filler price.

Contact Us Now
