Universal Assembly Line Labeling Head (Panasonic PLC Control)


Availability:



Inquire

The "Engine" for Your Packaging Automation.

Designed for seamless integration, this Universal Labeling Head transforms any standard conveyor, flow wrapper, or packaging machine into a fully automatic labeling line. Whether you need to apply labels to the Top, Side, or Curved surfaces of products, its 6-Axis Adjustable Stand ensures perfect positioning without modifying your existing line. Powered by a robust Panasonic PLC and high-torque Leadshine Stepper Motors, it delivers consistent accuracy (±1mm) and reliability for 24/7 operation.

[Get Integration Specs] | [View Configuration]

Brand:
JEWSHIN

Product Brochure.pdf

Download the brochure to view specifications, features, and application details. Download Brochure

1038

Download

Product Description

Key Features & Advantages

Universal Compatibility:

Can be mounted on Conveyor Belts, Pillow Packaging Machines, or VFFS Machines.
Also serves as a Replacement/Upgrade Head for existing flat or round bottle labeling machines that have failing applicators.

Precision Drive & Control (The "Golden Combo"):

Brain: Uses a Panasonic PLC (Japan) and Touchscreen for glitch-free logic control and data processing.
Muscle: Driven by Leadshine Stepper Motors, ensuring precise label dispensing start/stop control, preventing label drift even at high speeds.
Eye: Equipped with DataSensor / Panasonic / Riko sensors for reliable object and label gap detection.

6-DOF Flexible Adjustment:

The mounting system features a single-rod structure with X/Y/Z 6-Degrees of Freedom. You can tilt, rotate, lift, or lower the head to label difficult angles (e.g., labeling the slope of a bottle or the side of a box).

Intelligent Operation:

Auto-Correction: Automatically detects label length.
Smart Sensing: "No Product, No Label" feature prevents waste.
User-Friendly: The Panasonic interface offers full fault diagnostics and Chinese/English operation modes.

Application Scenarios

Logistics & Warehousing: Applying shipping labels or barcodes to boxes on a roller conveyor.
Food Industry: Labeling flow-wrapped cookies, bread, or top-labeling frozen food trays.
Pharmaceuticals: Adding anti-counterfeit labels or "e-codes" to cartons.
Printing: Integration with inkjet feeders to label paper stacks or cards.

Technical Specifications

Parameter	Details
Labeling Speed	40 - 200 pcs/min (Adjustable)
Labeling Accuracy	± 1.0 mm
Label Width	20 - 150 mm
Label Length	6 - 250 mm
Control System	Panasonic PLC + Touchscreen
Drive System	Leadshine Stepper Motor & Driver
Dimensions	1100 (L) × 900 (W) × 1450 (H) mm
Voltage	AC 220V / 50Hz

Core Configuration (Brand List)

We use globally recognized components to ensure easy maintenance and longevity:

Component	Brand
PLC Controller	Panasonic (Japan)
Touchscreen	Panasonic (Japan)
Stepper Motor	Leadshine (Top Tier)
Stepper Driver	Leadshine
Label Sensor	DataSensor (Italy)
Object Sensor	Panasonic / Riko

Upgrade Your Line Without Buying a New Machine.

Add this labeling head to your current setup for an immediate boost in efficiency.

Get a Quote: Contact us for pricing on the Panasonic-controlled Labeling Head.
Compatibility Check: Send us a photo of your conveyor, and we will confirm if this head fits.
Custom Stands: We can fabricate floor stands or mounting brackets to suit your facility.
