T-360 Automatic Horizontal Round Bottle Labeling Machine (For Vials & Cylinders)


Availability:



Inquire

The Solution for Unstable Cylindrical Products.

The T-360 (Model T-219) is engineered for products that are too thin, too light, or too top-heavy to stand upright on a standard conveyor. By utilizing a Horizontal Roller Conveyor system, it allows products like Ampoules, Vials, Batteries, Sausages, and Tape Rolls to travel flat ("lying down") for precise labeling. Powered by a Delta Servo Motor and controlled by a WECON Touchscreen, it ensures high-speed precision for pharmaceutical, cosmetic, and stationery industries.

[Watch Video Demo] | [Get Configuration List]

Model:
T-360
Brand:
JEWSHIN

Product Brochure.pdf

Download the brochure to view specifications, features, and application details. Download Brochure

1038

Download

Product Description

Key Features & Advantages

Horizontal "Roller" Architecture:

Products are fed and transported horizontally. This eliminates the risk of bottles falling over, making it the only choice for slender objects (diameter 18-21mm in this specific config, but typically customizable) or lightweight cylinders.

High-Precision Servo Drive:

Equipped with a Delta Servo Motor (Taiwan) for the labeling station. This ensures the label is dispensed with sub-millimeter accuracy, crucial for small pharmaceutical vials where label alignment is strictly regulated.

Top-Tier Electrical Components:

Built for longevity with industry-standard parts: Schneider contactors, Omron relays, and Panasonic sensors. This ensures easy maintenance and global availability of spare parts.

Versatile Labeling:

Supports both Full Circumference (Wrap-around) and Positioning Labeling. Ideal for medical bottles requiring exact placement of barcodes or graduation marks.

Application Scenarios

Pharmaceuticals: Oral liquid bottles, Ampoules, Vials, Penicillin bottles, Test tubes.
Stationery & Hardware: Solid glue sticks, Pen barrels, Batteries (AA/AAA), Caulk tubes.
Packaging Materials: Sealing tape cores/cylinders (as mentioned in specs).
Cosmetics: Lipsticks, Mascara tubes, Eyeliner pencils.

Technical Specifications (Model T-219/T-360)

Parameter	Details
Labeling Speed	~21 pcs/min (Based on provided data*)
Applicable Diameter	Ø 18mm - 21mm (Specific config, customizable)
Applicable Height/Length	30mm - 250mm
Label Size	Length: 10-300mm \| Width: 10-150mm
Label Roll Max OD	300mm (Inner Core: 76mm)
Voltage & Power	AC 200-240V / 50-60Hz / 1KW
Air Pressure	5 KG (0.5 MPa)
Dimensions	2050 (L) × 680 (W) × 1450 (H) mm
Weight	~200 KG

*Note: Speed typically varies significantly based on product size and feeding method. Please consult us for higher speed options.

Premium Configuration List (Brand Assurance)

We use global top-tier brands to ensure your production never stops:

Component	Brand	Origin/Quality
PLC / Touchscreen	WECON	Reliable HMI
Servo Motor	Delta	Taiwan (High Precision)
Photoelectric Sensor	Panasonic	Japan (Fast Response)
Relay	Omron	Japan
Contactor	Schneider	France
Stepper Motor/Driver	SAIYAN / YAKO	High Performance
Bearings	NSK / HRB	Japan / Top China
Speed Motor	DEBAL	German Tech

Stop Bottles from Falling. Switch to Horizontal Labeling.

If your product is difficult to stand up, the T-360 is the answer. Secure your production stability today.

Get a Quote: Contact us for pricing on the T-360 Horizontal Labeler.
Send Samples: Mail us your vials or tubes, and we will test the labeling precision for you.

[Contact Us Now] or [Chat via WhatsApp]
